FEATURES
- Easy installation: drill holes for the Rinser and Drain
- Robust 18 gauge stainless steel construction
- Welded corners, finished smooth for safety and appearance
- Fast draining, precision louvered screen
- Center-mounted solid brass drain
Rinser Water Inlet Installation
- Always check local plumbing codes first
- Install inline water regulator set at 15 PSI from the street water supply (no greater, perfect operating pressure)
- Install inline way check valve from the street water supply (prevents pressure drop, which can cause leaking)
- Install inline shut-off for the rinser system from the street water supply (this must be turned off nightly)
- If teed into a soda system, make sure the system can handle the increased water demand. Have the plumber install a 45° 1/2″ O.D. barb for the drains if the line is not hard-plumbed into the system
